Factory making Dn150 Butterfly Valve - Bare stem flanged butterfly valve – Jinbin Valve Detail:

Double Flange Bare stem Butterfly Valve

Bare stem flanged butterfly valve

Size: 2”-48” / 40mm – 1200 mm

Design standard: API 609, BS EN 593, GB T12238.

Face-to-Face dimension: API 609, BS 5155, ISO 5752.

Flange Drilling: ANSI B 16.1, BS4504, DIN PN 10 / PN 16, JIS 5K, 10K, 16K.

Test: API 598.

Bare stem flanged butterfly valve

Working Pressure	10 bar / 16 bar
Testing Pressure	Shell: 1.5 times rated pressure, Seat: 1.1 times rated pressure.
Working Temperature	-10°C to 80°C (NBR) -10°C to 120°C (EPDM)
Suitable Media	Water, Oil and gas.

Bare stem flanged butterfly valve

Parts	Materials
Body	Cast iron, ductile iron, carbon steel
Disc	Nickel ductile iron / Al bronze / Stainless steel
Seat	EPDM / NBR / VITON / PTFE
Stem	Stainless steel / Carbon steel
Bushing	PTFE
“O” ring	PTFE
Worm gearbox	Cast iron / Ductile iron

Bare stem flanged butterfly valve

This kind of butterfly valve is widely utilized in foodstuff, pharmacy, chemical industry etc. and industrial environmental protection, water treatment, high building, water supply and drain tubing line open or close or adjusting medium.

Bare stem flanged butterfly valve
