fire rising stem resilient seat gate valve

fire rising stem resilient seat gate valve Featured Image
  • fire rising stem resilient seat gate valve

Short Description:

fire rising stem resilient seat gate valve Nominal diameter: DN50- 400 Working pressure: PN10/16Bar Face-to-face:  EN558 Series10 Connection:  ANSI B 125LB flange. Tightness check: API 598    ISO 5208   EN12226-2 Epoxy fusion coating. Working Pressure PN16 Testing Pressure Shell: 1.5 times rated pressure, Seat: 1.1 times rated pressure. Working Temperature -10°C to 150°C Suitable Media Water, sewage water   Parts Materials Body cast iron Dis...


  • FOB Price: US $10 - 9,999 / Piece
  • Min.Order Quantity: 1 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
    • WhatsApp

    Product Detail

    Product Tags

    fire rising stem resilient seat gate valve

    125LB Cast iron rising stem flange gate valve

    Nominal diameter: DN50- 400

    Working pressure: PN10/16Bar

    Face-to-face:  EN558 Series10

    Connection:  ANSI B 125LB flange.

    Tightness check: API 598    ISO 5208   EN12226-2

    Epoxy fusion coating.

    125LB Cast iron rising stem flange gate valve

    Working Pressure

    PN16

    Testing Pressure

    Shell: 1.5 times rated pressure,

    Seat: 1.1 times rated pressure.

    Working Temperature

    -10°C to 150°C

    Suitable Media

    Water, sewage water



    125LB Cast iron rising stem flange gate valve

    Parts

    Materials

    Body

    cast iron

    Disc

    stainless steel / Ductile iron

    Seat

    stainless steel

    Stem

    2Cr13/SS431/ SS304

    Stem nut

    Bronze
