Tuam Tshoj stainless hlau phab ntsa mounted sluice rooj vag valve/dej penstock nrog kos Chaw tsim tshuaj paus thiab tsum |Jinbin Valve

stainless hlau phab ntsa mounted sluice rooj vag valve / dej penstock nrog kos duab

Lus piav qhia luv luv:

stainless hlau sluice gate valve / dej penstock nrog kos duab Lub valve no tsuas yog siv nyob rau hauv cov dej phwj kho cov nroj tsuag, waterplants, kua thiab irrigation, ib puag ncig tiv thaiv, hluav taws xob, channel thiab lwm yam dej num los txiav tawm, tswj ndlwg, thiab tswj dej theem.Yuav muab faib ua plaub hom 1.channel hom, siv nyob rau hauv nruab nrab ntawm lub channel, peb-txoj kev sealing 2.Wall type: siv nyob rau hauv inlet thiab qhov hluav taws xob ntawm phab ntsa rau qhib los yog kaw, plaub txoj kev foob 3.Kho hom: rau kho size t...

FOB Nqe:US $ 10 - 9,999 / Daim

Min. Order Quantity:1 Daim / Daim

Muaj peev xwm muab khoom:10000 Daim / Daim ib hlis

Loj:DN100-DN4000

Khoom siv lub cev:stainless hlau

Cov khoom siv zaum:EPDM

Customizable khoom:Stainless hlau / Carbon hlau / Duplex steel

Nruab nrab:Dej, Dej Dej, Dej Hiav Txwv, Acid

Siab::6m Lub taub hau dej

Xa email rau peb Download tau li PDF

Product Detail

Khoom cim npe

stainless hlau sluice rooj vag valve / dej penstock nrog kos duab

High kub qhov cua valve

Lub valve no tsuas yog siv rau hauv cov dej phwj tuaj kho cov nroj tsuag, waterplants, kua thiab irrigation, ib puag ncig tiv thaiv,
hluav taws xob, channel thiab lwm yam haujlwm los txiav tawm, tswj kev ntws, thiab tswj cov qib dej.Muaj peev xwm muab faib ua plaub hom

1.channel hom, siv nyob rau hauv nruab nrab ntawm lub channel, peb-txoj kev sealing
2. Phab ntsa hom: siv nyob rau hauv inlet thiab qhov hluav taws xob ntawm phab ntsa rau qhib los yog kaw, plaub txoj kev foob
3. Kho hom: kho qhov loj ntawm cov dej ntws

4. Weir hom: rau kev kho dej theem.Lub sluice gate valve yog corrosion resistant, muaj kev sib khi zoo, lub neej ntev thiab kev saib xyuas yooj yim.

Specification:

Loj	DN100-DN4000
Siab	0.05 Mpa / 0.1 Mpa / 0.15 Mpa / 0.25 Mpa
Tus qauv tsim	ISO10631/JB/T8692
Test txuj	GB / T13927 / API 598 / ISO 5208
Hom:	Channel hom / phab ntsa hom
Kub:	≤80 ℃
Lub taub hau ua haujlwm	Lub taub hau siab ≤10m-H2O, rov qab pressre≤2m-H2O
Actuator:	Phau ntawv / hluav taws xob / penufactic
Txuj	Cov neeg siv khoom xav tau
Nruab nrab	Dej, dej phwj tuaj, dej hiav txwv, acid media
MOQ	1 Teeb

High kub qhov cua valve

Lub cev	Carbon steel / SS / cam khwb cia hlau / super duplex alloys
Rooj vag	Carbon steel / SS / cam khwb cia hlau / super duplex alloys
Ncej	SS304/SS316/SS416
Kev sib khi	EPDM / NBR / tooj dag / tooj liab
Bolts & Ceev	Stainless hlau
