The stainless steel ball valve is a common type of valve, and its working principle is based on the fit between the round through hole on the ball and the seat. When the valve is opened, the ball’s through hole is aligned with the pipe axis, and the medium can freely flow from one end of the pipe to the other end through the through hole on the ball, and the fluid passage is smooth and the resistance is small. （Picture Ball valve size is DN20）

When the metal ball valve needs to be closed, the ball is rotated so that the through hole on the ball is perpendicular to the pipeline axis, and the ball completely blocks the pipeline, thus cutting off the flow of the medium. The design of the dual connector makes the valve more convenient when installing and disassembling, and can be flexibly connected and separated from the pipe for easy maintenance and replacement.

PPR Stainless ball valve has many advantages:

1.Convenient operation

Only need to rotate 90 degrees to achieve full opening or full closing of the valve, simple and fast operation, can effectively improve work efficiency.

2.Good sealing performance

Special sealing materials and structural design are used between the ball and the seat, which can achieve good sealing effect, effectively prevent media leakage, and ensure the safe operation of the pipeline system.

3.Large circulation capacity

When the sphere is opened, the channel is almost unhindered, the medium can pass smoothly, has a large flow capacity, and can meet the working requirements of large flow.

4.Strong corrosion resistance

According to different media and working environment, choose the right material, such as stainless steel, copper, etc., with good corrosion resistance, extend the service life of the valve.

5.Flexible installation

The duplex design allows flexible adjustment of its position during installation, which is convenient to connect with pipes of different diameters and different positions, reducing the installation difficulty.
